Special Purpose Containers Specification
Power to lead
Container Specification
Container Specification
20' Open Top Special Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 20' | 8' | 8' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 5,890 - 5,910 | 2,337 - 2,352 | 2,340 - 2,388 |
| Door Openings (mm) | | Width | Height |
| | 2,320 - 2,342 | 2,273 - 2,305 |
| Weights (kg) | Gross | Tare | Payload |
| 30,480 | 2,230 - 2,680 | 27,800 - 28,250 |
| Volume (m³) | | | 31.9 - 32.8 |
20' Flat Rack Special Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 20' | 8' | 8' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 6,058 | 2,438 | 2,219 - 2,234 |
| Door Openings (mm) | | Width | Height |
| | - | - |
| Weights (kg) | Gross | Tare | Payload |
| 30,000 / 40,000 | 2,600 - 2,960 | 27,400 - 37,040 |
40' Open Top Special Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 40' | 8' | 8' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 12,034 - 12,050 | 2,348 - 2,352 | 2,331 - 2,352 |
| Door Openings (mm) | | Width | Height |
| | 2,337 - 2,342 | 2,273 - 2,340 |
| Weights (kg) | Gross | Tare | Payload |
| 30,480 | 3,720 - 4,250 | 26,230 - 26,760 |
| Volume (m³) | | | 31.9 - 32.8 |
40' Open Top High Cube Special Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 40' | 8' | 9' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 12,032 | 2,352 | 2,655 |
| Door Openings (mm) | | Width | Height |
| | 2,340 | 2,585 |
| Weights (kg) | Gross | Tare | Payload |
| 30,480 / 32,500 | 4,300 - 4,400 | 26,180 - 28,200 |
| Volume (m³) | | | 75.1 |
40' Flat Rack Special Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 40' | 8' | 8' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 12,182 | 2,438 | 1,978 |
| Door Openings (mm) | | Width | Height |
| | - | - |
| Weights (kg) | Gross | Tare | Payload |
| 45,000 | 5,180 | 39,820 |
20' Standard Reefer Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 20' | 8' | 8' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 5,558 | 2,300 | 2,324 |
| Door Openings (mm) | | Width | Height |
| | 2,296 | 2,290 |
| Weights (kg) | Gross | Tare | Payload |
| 230,480* | 2,500 - 3,050* | 27,100 - 27,980* |
| Volume (m³) | | | 30.00 |
40' High Cube Reefer Container
| Exterior Dimensions (foot) | Length | Width | Height |
| 40' | 8' | 9' 6'' |
| Interior Dimensions (mm) | Length | Width | Height |
| 11,582 - 11,651 | 2,296 - 2,310 | 2,552 - 2,607 |
| Door Openings (mm) | | Width | Height |
| | 2,288 - 2,310 | 2,490 - 2,576 |
| Weights (kg) | Gross | Tare | Payload |
| 34,800 | 4,260 - 4,900 | 29,900 - 30,540 |
| Volume (m³) | | | 67.5 / 70 |
